Printer

Zebra - ZT230

Specifications are provided for reference and are based on printer tests using Zebra brand ribbons and labels. Results may vary in actual application settings or when using other than recommended Zebra supplies. Zebra recommends always qualifying any application with thorough testing.

Send Inquiry

Standard Features

  • 203 dpi print resolution (8 dots/mm)
  • Thin film print head with E 3® Element Energy Control
  • Direct thermal printing of bar codes, text, and graphics
  • USB 2.0 and RS-232 Serial Ports
  • Dual media sensors - transmissive and reflective sensing technology, selectable through software or front panel
  • Media supply hanger designed for 1‖ (25mm) through 3‖ (76mm) core diameters
  • Side loading metal print mechanism with head open lock withstands general wear & tear and facilitates media loading.
  • Sleek industrial design simplifies printer operation while providing pleasing styling for commercial applications
  • Printer Construction

Factory Installed Printer Options

  • Thermal Transfer Core-to-Core Ribbon Handling System
  • Print head 300 dpi (12 dots/mm)
  • A front mount, passive peel option, w/ no take-up spindle
  • A front mount guillotine cutter
  • Liner Take-Up for ZT230 only, rewinds entire 8‖ roll of liner (includes peel option)

ZebraLink Solutions Software

  • ZebraDesigner Pro – An intuitive, easy-to-use software program for creating complex label designs (option).
  • ZebraDesigner – Offers basic features for simple label design
  • ZebraNet Bridge Enterprise – Centrally manage Zebra printers from a single PC screen anywhere on your global network.
  • ZebraDesigner printer drivers – for 32 bit and 64 bit Windows XP, 2008, Vista, Windows 7
  • CUPS Driver - Linux/Unix drivers available at CUPS.org

Documents

Media Specifications

  • Media types: continuous, die-cut, or black mark, notch
  • Media thickness (label and liner): 0.003”/0.076 mm to 0.012”/0.305 mm
  • Maximum media roll size: 8.0”/203 mm O.D. on a 3”/76 mm I.D. core
  • Media width (label and liner): 0.79”/20 mm to 4.5”/114 mm
  • Maximum non-continuous label length: 39”/991 mm

Physical Characteristics

  • Height: 15.5”/393.7 mm
  • Width: 10.31”/261.9 mm
  • Depth: 20.38”/517.5 mm
  • Weight: 50 lbs/22.7 kg

Media Specifications

  • Media types : Continuous, die-cut, notch, black-mark.
  • Maximum non-continuous label length : 39" (991mm)
  • Media web width (label and liner) : 0.75" (19.4mm) to 4.50" (114mm)
  • Minimum label length : Tear-off mode: 0.7" (17.8mm); Peel mode: 0.8" (20.3mm); Cutter: 1.0‖ (25.4mm);
  • Media thickness (label and liner) : 0.003" (0.076mm) to 0.010" (0.25mm)
  • Maximum media roll dimensions : 8.0" (203mm) O.D. on a 3" (76mm) I.D. core; 6.0‖ (152mm) O.D. on a 1‖ (25mm) I.D. core;

Optional Features

  • Thermal Transfer Core-to-Core Ribbon Handling System
  • Print head 300 dpi (12 dots/mm)
  • A front mount, passive peel option, w/ no take-up spindle
  • A front mount guillotine cutter
  • Liner Take-Up for ZT230 only, rewinds entire 8‖ roll of liner (includes peel option)
