Printer

Zebra - 105SL Plus

The 105SLPlus is designed to easily fit into existing operations. The printer comes with multiple standard connectivity options including Parallel, Serial, USB and Ethernet coupled with full backward compatibility—making integration fast and simple.

Send Inquiry

Standard Features

  • Full-function front panel and large multilingual back-lit LCD display—with user-programmable password protection
  • Thin film printhead with Element Energy Equalizer™ (E 3 ™) for superior print quality
  • 8 MB Flash memory
  • Serial RS-232 and bi-directional parallel ports— with auto detect
  • USB 2.0
  • Dual media sensors—transmissive and reflective, selectable through software or front panel
  • Internal ZebraNet ® 10/100 Print Server— supports 10Base-T, 100Base-TX, and fast Ethernet 10/100 auto-switching networks.

Ribbon Characteristics

  • Standard Lengths: 1476’/450 m or 984’/300 m Provides 2:1 and 3:1 media roll to ribbon ratios
  • Maximum ribbon roll size: 3.2”/81.3 mm O.D. on a 1.0”/25.4 mm I.D. core
  • Ribbon wound coated-side out
  • Ribbon width: 0.79”/20 mm to 4.33”/110 mm

Options and Accessories

  • 300 dpi
  • Cutter and catch tray
  • Media rewind spindle—internal finished roll rewind or passive-peel with liner take-up spindle 64 MB On-Board Linear Flash Memory (factory installed only)
  • Scalable and international fonts

Documents

Media Specifications

  • Media types: continuous, die-cut, or black mark, notch
  • Media thickness (label and liner): 0.003”/0.076 mm to 0.012”/0.305 mm
  • Maximum media roll size: 8.0”/203 mm O.D. on a 3”/76 mm I.D. core
  • Media width (label and liner): 0.79”/20 mm to 4.5”/114 mm
  • Maximum non-continuous label length: 39”/991 mm

Physical Characteristics

  • Height: 15.5”/393.7 mm
  • Width: 10.31”/261.9 mm
  • Depth: 20.38”/517.5 mm
  • Weight: 50 lbs/22.7 kg

Fonts and Character Sets

  • Zebra Global printing solution including Unicode™
  • Swiss 721 font standard
  • Bitmap fonts A to H and GS symbols are expandable up to 10 times, height- and width- independent
  • Smooth-scalable font Ø (CG Triumvirate™ Bold Condensed) is expandable dot-by-dot, height- and width-independent
  • IBM ® Code Page 850 International Characters
  • Contains UFST ® from Agfa Monotype Corporation
  • Firmware support for downloadable TrueType™ fonts
  • Additional fonts available
  • 2 MB user available non-volatile memory storage for downloadable objects
