Printer

Print Method Thermal Transfer / Direct Thermal

• Resolution 203 dpi (8 dots/mm)
• Print Speed 5IPS (127 mm/s)
• Print Width 4.25" (108 mm)
• Print Length Min. 0.16” (4 mm)**; Max. 68” (1727 mm)
• Memory 8MB Flash (4MB for user storage) / 16MB SDRAM
• Sensor Type Adjustable reflective sensor. Fixed transmissive sensor, central aligned

Media Types

• Continuous form, gap labels, black mark sensing, and punched hole;
• label length set by auto sensing or programming Width : 1” (25.4 mm) Min. - 4.64” (118 mm) Max. Thickness : 0.003” (0.06 mm) Min. - 0.01” (0.25 mm) Max.
• Label roll diameter : Max. 5” (127 mm) Core diameter : 1”, 1.5”, 3" (25.4 mm, 38.1 mm, 76.2 mm)

Documents

•

  Data Sheet CN
  GODEX-500U-data-sheet-cn.pdf

•

  Broch EN
  GODEX-500U-broch-en.pdf
